Model NO.: JINMA 504C Usage: Farm Tractor, Garden Tractor, Lawn Tractor Drive Wheel: 4WD Fuel: Gas / Diesel Size: Medium Condition: New Trademark: JINMA Tractor Specification: CE EPA HS Code: 87019011 Type: Wheel Tractor Certification: CE, EPA, CCC, EEC Emission Standard: Euro IV Service Life: 6-10 Years Color: Red Power-Horse: 50 Package: Iron Shelf Origin: Yancheng Jiangsu
- Tractor model
- JM-504C
- Drive type
- 4WD
- Overall dimensions L×W×H (mm)
- 3385X1435X2133
- Front wheel track (mm)
- 1200
- Rear wheel track (mm)
- 1150~1450
- Wheel base (mm)
- 1896
- Ground clearance (mm)
- 342
- Rated traction force (N)
- 9800
- Construction mass (kg)
- 1650
- Minimum turning radius (m)
- 4.6
- Theoretical speed — Forward (km/h)
- 2.02,2.56,4.16,6.60,8.61,10.87,17.7,28.07
- Theoretical speed — Reverse (km/h)
- 1.89,8.04
- Engine model
- 4G33T
- Engine type
- 4-cylinder, Vertical,water cooled, 4 stroke cycle
- Rated power (kw/hp)
- 36.8/50
- Rated speed (rpm)
- 2300
- Bore × stroke (mm)
- 95×115
- Total displacement (L)
- 3.26
- Clutch
- 10″ single stage
- Gear box
- (4+1)×2
- Main drive
- One Pair of Spiral Bevel Gearing
- Differential
- Bevel Gear
- Differential lock
- Jaw Lock
- Final transmission
- Spur Gear,External,Gearing
- Front tyre
- 7.50-16
- Rear tyre
- 11.2-28
- Steering system
- Full Hydraulic Steering
- Brake
- Disc type
- Lifting capacity at 610mm behind lift point (N)
- 6600
- 3-point suspension
- Category:I
- PTO rotating speed (rpm)
- 540/720 or 540/1000
- PTO spline size
- 6-∮35Rectangular Spline
